Harley-Davidson V-Rod Oil Change: Ultimate Step-by-Step Guide

Changing the oil on your Harley-Davidson V-Rod (VRSC, VRSCD, VRSCR) is one of the most important maintenance tasks you can do. Because the V-Rod features a high-performance, liquid-cooled engine designed in part by Porsche, using the right specs and materials is non-negotiable.

This guide follows the official Harley-Davidson service manual to help you get a dealership-quality oil change at home.

Quick Specs & Requirements

Item	Specification
Oil Capacity	5 Quarts (approx. 4.3 – 4.7 Liters)
Oil Type	20W-50 Synthetic or Semi-Synthetic Motorcycle Oil
Drain Plug Torque	22–30 ft-lbs (30–40 Nm)
Filter Torque	Hand tight + 2/3 to 1 full turn

Essential Tools Needed

• 17mm socket bit and wrench (The V-Rod is a metric bike!)
• Oil filter wrench
• Torque wrench (capable of 22–30 ft-lbs)
• Oil drain pan and funnel
• New Oil Filter: (HD Part #63793-01K, K&N 174B/174C, or FRAM6100)

Step-by-Step Instructions

1. Warm Up and Drain

To really do the best thing for your motor, start by riding your motorcycle for 5–10 minutes to reach operating temperature. Warm oil flows a lot more freely and that carries away more contaminants.

Place your V-Rod on a level surface (either with a wheel vise or with a friend holding the bike upright for you).

Remove the oil filler cap first to allow for better airflow and to make sure it isn’t seized before draining the oil out.

Lastly, remove the 17mm drain plug located at the bottom of the engine to drain the old oil out.

2. Remove the Old Oil Filter

Use your oil filter wrench to unscrew the filter.

Pro Tip: Place a rag or a small tinfoil “trough” under the filter before removing it to prevent oil from dripping onto the front of your engine or frame.

Allow the oil to drain completely. Now’s a great time to do a little clean up if you’ve made any messes, take your dog for a walk, or just prep for the new filter.

3. Prep and Install the New Filter

Clean the filter mounting surface with a clean rag. Take your new oil filter and apply a thin layer of fresh 20W-50 oil to the rubber gasket to saturate it well.

• Screw the filter on until the gasket makes contact.
• Tighten it by hand another 2/3 to 1 full turn.
• Do not over-tighten with a wrench!

4. Reinstall the Drain Plug

Inspect the drain plug and clean any metallic debris off the magnetic tip.

Reinstall the plug and use your torque wrench to tighten it to 22–30 ft-lbs.

5. Add Fresh Oil

Pour just under 5 quarts of high-quality 20W-50 motorcycle oil.

While some manuals suggest 5 quarts, there’s a known conversion error where this results in overfilling the oil That’s because the motor has an oil cool, and oil lines in and out of the cooler, which keep quite a bit of oil in the motorcycle even after nothing is coming out of your drain plug.

I’d recommend starting at around 4.5 quarts, or 4.3 liters, and then check the level from there.

6. Verify Oil Levels

Start your engine and let it idle for a minute to circulate the oil through the new filter.

Shut it off and let it sit for 2 minutes.

With the V-Rod upright (not on the kickstand), remove the d the dipstick and wipe it clean.

With the motorcycle still upright, re-insert the dipstick and screw it in all the way, then remove it again. There will be a minimum and a maximum mark on the dipstick. Make sure the oil level is somewhere between the two.

• Too low? Add small increments.
• Too high? You’ll need to drain a small amount to avoid pressure issues.

Remember the motorcycle needs to be upright for the oil check to work accurately.

---

Why the V-Rod is Different

Unlike traditional air-cooled Harleys (EVO, Twin Cam, etc.) the V-Rod’s Revolution engine shares oil between the engine and the transmission. That means you only have one oil cavity to worry about, making the V-Rod one of the easiest Harleys to maintain yourself.

Expert Note: Always use oil specifically rated for motorcycles (JASO MA/MA2). Your standard automotive oil contains friction modifiers that can cause your wet clutch to slip and become damaged.

If you have any questions, leave them down below!
